RCYD Self-Discharging Permanent Magnetic Separator
Product Overview
The RCYD(C) Series Self-Discharging Permanent Magnetic Separators consist of neodymium-boron permanent magnetic cores, iron-rejecting belts, gear motors, frames, rollers and other components. They are used in conjunction with various conveyors to automatically remove ferromagnetic substances from non-magnetic materials, and are suitable for occasions where materials contain a relatively large amount of iron.
Main Technical Parameters
| Adaptive Bandwidth m | Rated Lifting Height h≤m | Magnetic Field Strength ≥mT | Material Thickness ≤mm | Driving Power km | Adaptive Belt Speed ≤m/s | Work | Weight kg | External Dimensions m | ||||
| A | B | c | D | E | ||||||||
RCYD(C)-5 | 500 | 150 | 60 | 80 | 1.5 |
4.5 |
连续 | 750 | 1900 | 735 | 935 | 950 | 753 |
RCYD(C)-6 | 600 | 175 | 60 | 120 | 1.5 | 920 | 2050 | 780 | 1030 | 1100 | 753 | ||
RCYD(C)-6.5 | 650 | 200 | 70 | 150 | 2.2 | 1200 | 2165 | 780 | 1080 | 1200 | 888 | ||
RCYD(C)-8 | 800 | 250 | 70 | 200 | 2.2 | 1400 | 2290 | 796 | 1280 | 1300 | 1088 | ||
RCYDC)-10 | 1000 | 300 | 70 | 250 | 3.0 | 2120 | 2660 | 920 | 1550 | 1400 | 1335 | ||
RCYD C)-12 | 1200 | 350 | 70 | 300 | 4.0 | 3350 | 2900 | 970 | 1720 | 1550 | 1515 | ||
RCYD(C)-14 | 1400 | 400 | 70 | 350 | 4.0 | 4450 | 3225 | 1050 | 1980 | 1800 | 1755 | ||
RCYD(C)-16 | 1600 | 450 | 70 | 400 | 5.5 | 6200 | 3420 | 1180 | 2210 | 1950 | 1850 | ||
RCYDC)-18 | 1800 | 500 | 72 | 450 | 7.5 | 8100 | 3580 | 1210 | 2450 | 2200 | 2130 | ||
RCYD(C)-20 | 2000 | 550 | 72 | 500 | 11 | 9700 | 3800 | 1300 | 2700 | 2400 | 2410 | ||
